1.1m3 Gold Beneficiation Machine Mining Froth Separator

Anhui Sinomining Machinery Co., Ltd
Contact Now

1.1m3 Gold Beneficiation Machine Mining Froth Separator

Brand Name : Y&X

Model Number : XJ Flotation Machine

Certification : Quality Management System Cerification

Place of Origin : China

MOQ : 1

Price : US$ 3000-10000 /per

Payment Terms : T/T

Delivery Time : 30

Packaging Details : Standard Shipping Packaging

Name : XJ Flotation Machine

Application : Mineral Flotation Machine

Energy : Energy Saving

Effective Volume of Single Cell : 1.10m³

Inner Dimensions of Cell : 1100×1100×1000mm

Handling Capacity : 0.6-1.6m³/min

Spindle Motor Power : 5.5kw

Single Cell Weight : 1450KG

Contact Now

Mining Flotation Cell Gold Beneficiation Machine Mining Forth Separator

Introduction

Flotation machine refers to the mechanical equipment that completes the flotation process. In the flotation machine, the ore pulp treated by adding reagents is stirred and aerated to selectively fix some of the ore particles on the bubbles; it floats to the surface of the ore pulp and is scraped out to form a foam product, and the rest remains in the ore pulp In order to achieve the purpose of separating minerals. There are many structural forms of flotation machines, and the most commonly used one is a mechanical agitation flotation machine.

Features
XJ flotation machine is a widely used model introduced from the form Soviet Union with a long history. Currently, it is still widely applied in the grading of mines.


Parameter

Models Effective volume of single cell Inner dimensions of cell Handling capacity Spindle motor Single cell weight
Models Power
mm m³/min kw kg
XJ-1.1 1.1 1100×1100×1000 0.6-1.6 Y132M2-6 5.5 1450
XJ-2.8 2.8 1750×1600×1100 1.5-3.5 Y160L-6 11 2340
XJ-5.8 5.8 2200×2200×1200 3.0-7.0 Y200L2-6 22 3560
XJ-8 8 2600×2600×1300 4.0-8.5 Y200L2-6/Y250M-8 22/30 4350
XJ-10 10 2900×2700×1400 5.0-10.0 Y200L2-6/Y250M-8 22/30 4960
XJ-16 16 2400×3100×1600 8.0-13.5 Y250M-8 30 8540
XJ-20 20 3600×3400×1700 10.0-17.0 Y280S-8 37 8720

Why choose our company machine?


Q1: Hi, are you a mining machinery manufacturer?
Answer: Yes, we are a professional manufacturer of mining machine. Our company welcomes customers to visit our factory at any time.

Q2: How long is the warranty period of your equipment? Does your company provide spare parts?
Answer: The warranty period of our machine is one year. For those wearing parts, we guarantee to provide high-quality parts for a long time.

Q3: How long does it take to deliver?
Answer: Production usually starts after receiving the advance payment. Small machine is guaranteed to be delivered within one month. Large-scale machine is guaranteed to be delivered within 2-3 months.

Q4: Do you provide machine operation guidance?
Answer: Yes. We have professional engineers for installation, commissioning and operation guidance.
